Smoke containment systems
Other News
Subscribe to FREE newsletter
| Apr 30, 2010 |
Smoke Guard manufactures a variety of smoke containment systems to meet code requirements and increase safety throughout your building. The grid below provides a basic overview of our products.
| Model 200 | Model 400 | Model 600 | Model 900 | Model 1500 |
|---|---|---|---|---|
| Opening width | ||||
| 42 inches and 48 inches only | Up to 5 feet wide | Custom sizes available | Up to 7 feet wide | 6-12 feet wide |
| Opening height | ||||
| Up to 10 feet high | Up to 10 feet high | Up to 10 feet high | Up to 9 feet, 10 inches high | Up to 12 feet high |
| Unit return sizes (projection from wall) | ||||
| Standard return available: 1 inch | Standard returns available: 1/2 inch, 3/4 inch, and 1 inch | Standard returns available: 1/2 inch, 3/4 inch and 1 inch. Custom returns available as well | Standard return available: 3/4 inch | Recessed and Surface Mount Guides options |
| Housing dimensions | ||||
| Housing widths: 55 and 64 inches. Height: 10.5 inches. Depth: 9 inches (plus return) | Housing widths: 55, 64 and 73 inches. Height: 10.5 inches. Depth: 9 inches (plus return) | Housing widths: 52, 56, and 63 inches. Height: 13 inches std or 9 inches with side mount motor. Depth: 7.5 inches (plus return) | Housing widths : 94.25 inches. Height : 16.25 inches. Depth: 11 inches | Effective height 12" Effective width 14" |
| Unit electronic control | ||||
| In electrical box mounted on the housing | In electrical box mounted on the housing | In separate electrical box that can be mounted next to unit housing or up to thirty conduit feet away | In electrical box mounted on the housing | In electrical box mounted on the housing |
| Emergency power source | ||||
| No internal emergency power source. Unit is fail safe and will deploy if primary power disrupted for more than 10 seconds. Unit can be connected to emergency power | No internal emergency power source. Unit is fail safe and will deploy if primary power is disrupted for more approximately 8 seconds. Unit can also be connected to emergency power | Each unit has battery that can power unit for up to ten days | Each unit has a battery that powers the unit for up to ten days | Each unit has a battery that powers the unit for up to ten days |
| Protection from temporary power failures | ||||
| A brief delay avoids nuisance deploys | A brief delay avoids nuisance deploys | Emergency power source takes over if AC power is disrupted | Emergency power source takes over if AC power is disrupted | Emergency power source takes over if AC power is disrupted |
| Curtain rewind switch | ||||
| Yes, located on both sides of curtain | Yes, located on both sides of curtain | Yes, located on both sides of curtain | Yes, located on both sides of curtain | Yes, there are two wall mounted switches located on each side of the curtain. |
| Curtain deploy switch | ||||
| Yes, located on controls inside housing | Yes, located on controls inside housing | Yes, key activated from wall switch | Yes, located on controls inside housing | Yes, located on controls inside the housing |
| Cove bases required | ||||
| No | No | No, for elevator openings up to 60 inches. Yes, for opening sizes beyond 60 inches | Yes | N/A |
| Auxiliary Rails/Guides | ||||
| Auxiliary rails for all units. Rails can be painted to match (see note in specification) | Auxiliary rails optional for these units if the elevator frame is ferrous and at lease 2" wide. If rails are used, they can be painted to match (see note in specification). | Auxiliary rails optional for these units if the elevator frame is ferrous and at lease 2" wide. If rails are used, they can be painted to match (see note in specification). | Auxiliary rails for all units. Rails can be painted to match (see note in specification) | Guides, recessed or surface mounted, are required on these units. |
