Accuride 2400 Series Delivers Precision Motion in an Ultra-Slim Profile
August 28, 2026
As commercial equipment becomes smaller and more technologically advanced, internal space is increasingly valuable. Self-service kiosks, medical devices, vending systems, retail displays and industrial equipment must accommodate electronics, controls and serviceable components within compact enclosures.
The Accuride 2400 Ultra-Slim Series addresses this design challenge with space-efficient linear motion hardware engineered to provide smooth, dependable movement without occupying unnecessary internal volume.
Making More Effective Use of Limited Space
Modern equipment may need to house numerous systems within a single enclosure, including:
- Power supplies and control boards
- Connectivity and communication modules
- Payment and transaction hardware
- Displays and user interfaces
- Components requiring regular service access
Conventional drawer slides were often developed for larger applications such as filing cabinets, storage drawers and toolboxes. Although suitable for those purposes, their dimensions may limit design flexibility when used in compact, electronics-intensive equipment.
Ultra-slim slides help engineers preserve usable internal space while still providing controlled movement and convenient access. Even a modest reduction in hardware dimensions can support higher component density, better airflow, easier maintenance and a smaller overall equipment footprint.
Compact Performance with the Accuride 2400 Series
Developed for installations where space is restricted, the Accuride 2400 Series combines a compact 20 mm height with smooth motion and durable construction. The range includes the 2415, 2421 and 2431, enabling designers to select a model suited to the extension and installation requirements of the application.
Important characteristics of the series include:
- An ultra-slim profile for space-conscious equipment designs
- Smooth and consistent movement
- Die-formed slide members for dimensional accuracy and durability
- Multiple models for different extension requirements
- Suitability for compact commercial and industrial equipment
Why Manufacturing Precision Matters
The quality of a slide’s movement depends not only on its dimensions, but also on the consistency of its manufactured profile. Accuride uses die-formed members in the 2400 Series to help achieve accurate alignment and controlled motion.
Roll forming and die forming are two established methods of producing slide members. Roll forming gradually shapes a continuous strip of steel as it passes through a sequence of rollers. This efficient process is well suited to high-volume production, although small dimensional variations may occur along the finished profile.
Die forming uses precision tooling in a stamping press to define the component geometry. The rigid tooling can provide tighter tolerances and greater consistency between individual slide members. In a ball-bearing slide assembly, this can contribute to:
- More uniform ball-race geometry
- Improved alignment between members
- Reduced variation between production batches
- Smoother and more controlled movement
Supporting the Next Generation of Equipment
Compact motion hardware has become an important consideration as equipment manufacturers integrate more functionality into smaller products. By combining an ultra-slim envelope with die-formed precision, the Accuride 2400 Series offers a practical motion solution for applications in which space, serviceability and consistent performance must all be carefully balanced.
